The tablet press machine is designed to compress dry powder or granular material into tablets with uniform size and weight. These are widely used in the pharmaceutical, nutraceutical, chemical, herbal, and food industries. Utilizing different dies, it can compress tablets into different shapes.
TYPES OF TABLET PRESS MACHINES
Classified by speed: low speed machine, mid speed machine, high speed machine
Classified by number of stations: single punch tablet press machine and rotary tablet press machine
Pharmaland supplies tablet press machines with various production capabilities to exactly match your needs. All machines are GMP compliant, easy to operate and maintain.
Features may vary on different models
The hopper or feeding machine is filled with powder or granules, after which the dosing unit fills the material is filled into dies.
In the pre-compression stage, the upper and lower punches are guided to deposit a a small amount of material into the die to remove the air. It also helps to shorten the following compression stage. The punches then pass material to the main compression rollers where a predetermined amount of pressure acts on them, resulting in a compact solid—a tablet with desired weight, thickness, and diameter.
After main compression, the upper punches are pulled by the upper guide returning them to the initial position. At the same time, the lower punches move upwards to eject the tablets out of the dies. The tablets are then transferred to the discharge port.
The single punch tablet press machine is a type of tablet press machine that is designed to compress dry powder or granular into tablets with uniform size and weight. They are widely used in the pharmaceutical, nutraceutical, chemical, herbal, and food industries for their ability to compress tablets into different shapes using different dies. Some single punch tablet press machines are designed with an automatic tablet ejection system that helps to improve the efficiency of the tablet production process.
If you’re looking for a single punch tablet press machine for your business, there are a few things you should keep in mind. First, you’ll need to decide what type of machine is right for your needs. There are manual, semi-automatic, and fully automatic single punch tablet press machines available on the market. Each type has its own advantages and disadvantages. Second, you’ll need to determine the production capacity you need. The single punch tablet press machine’s production capacity is typically measured in terms of tablets per hour or tablets per day. Third, you’ll need to consider the size and weight of the tablets you’ll be producing. The single punch tablet press machine’s die sizes range from 0.25″ to 12″ in diameter. And finally, you’ll need to decide what kind of warranty or service agreement you want. When it comes to choosing a single punch tablet press machine, there are a lot of factors to consider. But with a little bit of research, you’ll be able to find the perfect machine for your needs.
Still have questions? Our team of experts are here to help. Contact us today and we’ll be happy to answer any questions you have about single punch tablet press machines.
tablet press machines are classified by speed as low speed, mid speed, sub-high speed, and high speed. Depending on the number of dies, tablet press machines can be single punch or rotary. Some tablet press machines are designed for special purposes such as making scored tablets, bilayer tablets, or tablet with a hole in the center. tablet press machines can be equipped with various accessories such as tablet coating pan, dust extractor, or tablet polishing machine. The size and weight of tablet press machines vary depending on the type and model.
Most tablet press machines are automatic, however there are some manual tablet press machines available. Automatic tablet press machines have many advantages over manual tablet press machines such as increased production capacity, reduced operator fatigue, and improved tablet quality.
When selecting a tablet press machine, it is important to consider the intended use of the machine and the desired tablet output. Other factors to consider include tablet size and shape, tablet hardness, fill weight, and ejection force.
The tablet press machine is composed of an upper punch and a lower punch. The head of the upper punch (whose working position is downward) falls into the middle die hole from the upper end, and goes down a certain stroke to press the powder into tablets; the head of the lower punch (whose working position is upward) extends into the middle die hole to seal the bottom of the middle die hole. The upper punch lifts out of the hole. The lower punch rises to push the tablet out of the middle die hole to complete the tableting process.
The tablet press machine can be used for various kinds of pharmaceutical tablets, including uncoated tablets, coated tablets, sugar-coated tablets, and enteric-coated tablets. The tablet press machine can also be used for pressing granules into different shapes of tablets. There are many types of tablet press machines, such as single punch tablet press machine, rotary tablet press machine, and hydraulic tablet press machine.
The upper punch and lower punch are the two important parts of the tablet press machine. The upper punch is also called the die, and the lower punch is also called the punches. The tablet press machine works by using these two parts to press the powder into tablets. The upper punch falls into the middle die hole from the upper end, and goes down a certain stroke to press the powder into tablets. The lower punch extends into the middle die hole to seal the bottom of the tablet.
Standard seaworthy wooden case packing.
If there are any special requirements on packing, we can discuss further.
NOTE: The packaging is not designed for long term outside storage.
Machines are wrapped with plastic film for protection
Standard wood packaging for exporting
Loading goods by forklift
Beijing China
Shenzhen China
Pharmaland Technologies proudly stands behind each product sold.
One-year limited warranty and lifetime service are provided.
Machines in the project: A fully automated production line, including a coating machine, tablet press machine, filling machine, mixing machine and blister packing line. In 2016, Pharmaland met a prospective new client from Romania, who was a newcomer to the industry, who was skeptical about......
17 April, 2022 No comment
Machines in the project: a fully automated production line, including a mixing machine, coating machine, blister packaging machine line, pill press machine, filling machine, counting & packing line, etc. In 2018, an existing Pharmaland supplement client wanted to start supplement production in the USA. It......
17 April, 2022 No comment
Machines in the project: mixer, fluid bed dryer, coating machine, hard capsule filling machine, tablet press machine, powder and liquid sachet packing machine and counting line. In 2012, we were awarded a project to rebuild the GMP factory in South Africa which had sustained considerable......
31 March, 2022 No comment
I appreciate their quick response and give me clear guidance during installation, we are happy to work with this high-speed capsule filling machine.
Robert
They keep me updated during the machine production, doing well inspection before shipment, show me the video and ship everything on time. Good Job!
Zed
It is amazing that they prepared all documents which we needed in advance for customs clearance, some I didn't even know in advance, very professional!
Maria
This is the second time to buy a machine from PAG, they are the only supplier we trust, very good machine and they are very professional in customizing the production line for us.
Alfred
Very good experience to work with PAG, both the sales and their service are reliable, and the tablet press machine is easy to use and maintain.
Kenny
• We offer low-speed, mid-speed, sub-high-speed, and high-speed machines to meet your capacity need.
• Tablet size, shape, and compression pressure are also considerations.
• We can generally accommodate special configuration requests, such as preferred brands, etc.e any special request son configuration, such as nominated brands.
The machine can compress round tablets, irregular-shaped tablets, ring tablets, lettering tablets, bicolor tablets, etc. Once we know your needs, we will recommend the most suitable machine for you.
We have machines specialized designed for compressing effervescent tablets.
We can equip machines with a punch and die protection device, tablets rejection device, safety doors, automatic lubrication system, etc.
We offer a variety of machines to meet your needs—all as turnkey solutions.
Our professional service team can provide technical service both from China and Canada to customers anywhere in the world.
The design of each machine conforms with GMP requirements.
We can provide full documentation, such as IQ, OQ, PQ, DQ, and CE certificates.
We adhere to a strict quality control system, with careful in-process quality control and pre-shipment inspection to ensure that all machines shipped out are in excellent working condition.
We will supply a manual and a guidance video. If needed, onsite installation and training by one or two technicians can be arranged.
Pharmaland Technologies is a technology-based subsidiary of PAG Group, integrating manufacturing and trade, that specializes in supplying pharmaceutical and packaging machines.
The predecessor of PAG group is Honson Pharmatech, established in Canada in 1995.
Pharmaland mainly provides comprehensive solutions for manufacturers of all sizes, providing safe, GMP-compliant “turnkey” engineering equipment. With rich experience in pharmaceutical production, we not only provide customers with suitable machinery, but also provide suggestions for common processes.
We export machines worldwide, including Europe, America, Africa, and Asia.
Our machines have passed ISO 9001 quality system certification and CE certification. ”Quality First, Service Oriented” is our business philosophy. We are committed to providing high-quality pharmaceutical and packaging equipment and solutions for global manufacturers.
