Pharmaland Technologies provides comprehensive solutions for straight tube tablet filling, tablet automatic counting, roll paper packaging, automatic tube feeding, and roll paper bottle labeling lines for effervescent products.
This machine is independently researched, developed, and manufactured using advanced technology. We use parts and electrical components from world-famous brands. We guarantee all tablet contact parts by using SUS 316 high-quality stainless steel, so they fully meet GMP requirement. It utilizes a high-precision indexing mechanism, speed-regulating step motor, photo-electric sensor, proximity switch, and a PLC centralized control. It will automatically stop and sound an alarm under conditions of no tablet, no bottle, or no cover. To achieve reliable performance, it can detect bottles and covers in the loading process, and it has automatic tube loading, capping, filling, and discharging.
Caps are manually loaded into the hopper and vibrated into place in the rack for plugging.
Tablets are manually fed into the tablet hopper, then automatically positioned.
Bottles are manually loaded into the hopper. Then, they are unscrambled and aligned into tablet-filling position.
Once a bottle is detected, the tablet feeding cylinder will push the tablets into bottle.
Once the tablets have been fed into the bottle, the capping system will push the cap onto the bottle and close it automatically.
The effervescent tube filling and sealing machines work by firstly having the tablets poured into the hopper manually. The tablets are then screened before being automatically arranged into the orbit where they will enter the loading position. Next, the bottles are placed inside the bottle hopper manually before being fed into the filling position automatically. After this, caps are placed inside the oscillator plate which arranges them into the capping position before the effervescent tube filling and sealing machine automatically fills the bottle with tablets. Finally, the effervescent tube filling and sealing machine will cap the bottle. Consequently, this outlines how the effervescent tube filling and sealing machines work in general. If you have effervescent tablets that need to be filled and sealed, this is the machine for you.
The semi-automatic effervescent tube filling machine is an ideal option for small and medium-sized enterprises. The machine is very user-friendly, so you don’t need to have a lot of experience to use it. The semi-automatic effervescent tube filling machine is also very versatile, so you can fill different sizes and shapes of tubes. The semi-automatic effervescent tube filling machine is also very fast, so you can fill a lot of tubes in a short period of time.
If you’re looking for an effervescent tube filling machine, semi-automatic effervescent tube filling machine is your best bet. It’s affordable and user-friendly, so you don’t need to have a lot of experience to use it, and it offers a lot of flexibility. Plus, it’s fast, so you can get a lot of work done in a short period of time. Contact us today to learn more about semi-automatic effervescent tube filling machines!
One advantage of fully automatic effervescent tube filling machines is that they have a high degree of automation. This means that they can improve work efficiency and save labor costs. Additionally, these machines can also help to improve product quality by ensuring that each tube is filled with the correct amount of product. Finally, fully automatic effervescent tube filling machines can also help to reduce the amount of waste that is generated during the production process. If you are considering investing in a fully automatic effervescent tube filling machine, then it is important to weigh up all of the advantages and disadvantages before making a decision. However, if you are looking for a way to improve work efficiency and save money, then a fully automatic effervescent tube filling machine may be the right choice for you.
Standard seaworthy wooden case packing.
If there are any special requirements on packing, we can discuss further.
NOTE: The packaging is not designed for long-term outside storage.
Machines are wrapped with plastic film for protection
Standard wood packaging for exporting
Loading goods by forklift
Beijing China
Shenzhen China
Pharmaland technologies proudly stands behind each product sold.
One-year limited warranty and lifetime service are provided.
Machines in the project: A fully automated production line, including a coating machine, tablet press machine, filling machine, mixing machine and blister packing line. In 2016, Pharmaland met a prospective new client from Romania, who was a newcomer to the industry, who was skeptical about......
17 April, 2022 No comment
Machines in the project: a fully automated production line, including a mixing machine, coating machine, blister packaging machine line, pill press machine, filling machine, counting & packing line, etc. In 2018, an existing Pharmaland supplement client wanted to start supplement production in the USA. It......
17 April, 2022 No comment
Machines in the project: mixer, fluid bed dryer, coating machine, hard capsule filling machine, tablet press machine, powder and liquid sachet packing machine and counting line. In 2012, we were awarded a project to rebuild the GMP factory in South Africa which had sustained considerable......
31 March, 2022 No comment
I appreciate their quick response and give me clear guidance during installation, we are happy to work with this high-speed capsule filling machine.
Robert
They keep me updated during the machine production, doing well inspection before shipment, show me the video and ship everything on time. Good Job!
Zed
It is amazing that they prepared all documents which we needed in advance for customs clearance, some I didn't even know in advance, very professional!
Maria
This is the second time to buy a machine from PAG, they are the only supplier we trust, very good machine and they are very professional in customizing the production line for us.
Alfred
Very good experience to work with PAG, both the sales and their service are reliable, and the tablet press machine is easy to use and maintain.
Kenny
We’ll need to know the tablet size, the tube size, the number of tablets per tube, and what capacity will be needed. A photo of the tube will be helpful.
Yes, we’re happy to customize machines for your specific needs.
Generally, we offer semi-automatic and fully automatic machines.
We offer a variety of machines to meet your needs—all as turnkey solutions.
Our professional service team can provide technical service both from China and Canada to customers anywhere in the world.
The design of each machine conforms with GMP requirements.
We can provide full documentation, such as IQ, OQ, PQ, DQ, and CE certificates.
We adhere to a strict quality control system, with careful in-process quality control and pre-shipment inspection to ensure that all machines shipped out are in excellent working condition.
We will supply a manual and a guidance video. If needed, onsite installation and training by one or two technicians can be arranged.
